CLT70STC Controller - Power Supply With Screw Counter

Product Code:  HIS CLT70STC
Brand Name:    Hios


Description


Screw Counter - No screws overlooked!

  • Compact design with built-in driver controller and counter.

  • Screw counter for up to 99 screws, depending on the work piece.

  • Displays the remaining screw count each time you drive a screw.

  • Buzzer sounds when a screw is overlooked or when all screws have been driven.

  • Screw counter is automatically reset and put into the standby mode when all screws have been driven. The workpiece-set signal input when the next workpiece is set breaks the standby mode. (When the counter is in the standby mode, you cannot activate the driver.)

  • Count timer prevents double counting of screws tightened for conformation or for the second time.

Working efficiency enhanced by many functions

  • Controls external devices connected via 24V DC terminal.

  • Prevents drivers from being activated by mistake. You can activate a driver only while jig holds a workpiece.

  • Workpiece-set timer presets the time required for setting and fixing a workpiece with jig.

  • Workpiece-reset timer presets the time required for releasing a workpiece from jig when all screws have been driven.

  • Connectors for connection with multiple power supply units for sequential operation of multiple drivers.

  • Disabling the counter function will allow you to fit one of the Hios electric drivers, and to use this power supply for the driver only. (The model in which combination is possible: CL-2000, 3000, 4000, 6000, 6500, 7000, a-4500, 5000, 6500)

Screw driving while idling a push-start type electric driver, or repeated on and off operation of a driver in a short period of time may result in malfunction of this equipment. Please contact your dealer should such operation be needed.





Specification


Screw Counter - No screws overlooked!

  • Compact design with built-in driver controller and counter.

  • Screw counter for up to 99 screws, depending on the work piece.

  • Displays the remaining screw count each time you drive a screw.

  • Buzzer sounds when a screw is overlooked or when all screws have been driven.

  • Screw counter is automatically reset and put into the standby mode when all screws have been driven. The workpiece-set signal input when the next workpiece is set breaks the standby mode. (When the counter is in the standby mode, you cannot activate the driver.)

  • Count timer prevents double counting of screws tightened for conformation or for the second time.

Working efficiency enhanced by many functions

  • Controls external devices connected via 24V DC terminal.

  • Prevents drivers from being activated by mistake. You can activate a driver only while jig holds a workpiece.

  • Workpiece-set timer presets the time required for setting and fixing a workpiece with jig.

  • Workpiece-reset timer presets the time required for releasing a workpiece from jig when all screws have been driven.

  • Connectors for connection with multiple power supply units for sequential operation of multiple drivers.

  • Disabling the counter function will allow you to fit one of the Hios electric drivers, and to use this power supply for the driver only. (The model in which combination is possible: CL-2000, 3000, 4000, 6000, 6500, 7000, a-4500, 5000, 6500)
